CU 7727 4P flex Industrial FRNC UL
Flexible data cable, S/FTP, Category 7, AWG27, Euroclass Dca
600 MHz
1 Inner conductor: AWG27, bare copper wire, stranded
2 PE insulated conductor: Ø 1.01 mm
3 Screen (pair): Alu PETP foil
4 Overall screen: tinned braided copper
5 Outer sheath: FRNC/LSZH
Product variants & stock
| Article No. | Stock | Product | Reaction to fire | Dimensions n x p x [mm² (AWG)] | Outer sheath colour | Outer sheath dimensions [mm] | CU rate [kg/km] | Weight [kg/km] | Fire load [kWh/m] | Packing unit | GTIN / EAN |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 19467900DK | CU 7727 4P Flex | Dca-s2,d1,a1 | 4 x 2 x 0.108 (AWG27) | grey | 6.2 | 15.2 | 43 | 0.14 | 1000 m drum | 40393910216783 |
Technical specifications
Electrically and mechanically superior quality Cat.7 flexible cable - exceeds the requirements of ISO/IEC 11801, IEC 61156-6, EN 50173-1 and EN 50288-4-2.
Excellent shielding effect due to individually screened pairs and overall copper braid.
Easy wire identification and termination due to different coloured wires.
Compatible with all current connecting hardware in accordance with EN 50173, ISO/IEC 11801 and 60603-x.
| Repeated bending | 1000 cycles |
|---|---|
| Tensile strength (4P) | 50 N |
| Minimal crush resistance / 10cm | 600 N |
| Minimum number of impacts | 10 |
| AWG | 27 |
| Solid / Flex | Stranded wire (flexible) |
| Minimum bending radius | 25 mm |
| As patch cord and for flexible wiring in machine control cabinets and for general industrial applications, where UL certified products are required. For the transmission of digital and analogue voice, video and data signals. Suitable for all ICT network applications up to class F applications (600 MHz) in accordance with EN 50173-1 and ISO/IEC 11801. Optimized for Ethernet and Ethernet based protocols up to 10GBase-T. Applicable for Power over ethernet PoE / PoE+ / 4PPoE (100 Watt). |
| Category | Cat.7 |
|---|---|
| GBit/s | Up to 10 Gbit/s |
| Loop resistance at 20 °C | 350 Ω/km |
| Operating capacity | 47 pF/m |
| Impedance at 100 MHz, ±5Ω | 100 Ω |
| NVP % | 72 |
| Delay skew | 4 ns/100 m |
| Shielding | shielded |
| Near end unbalance attenuation LCL at 1-600 MHz | 40 dB |
| Transfer impedance | 10 mΩ/m |
| Coupling attenuation | 70 dB |
| Segregation class | c |
| Installation temperature | 0 °C - +50 °C |
|---|---|
| Operating temperature | -20 °C - +60 °C |
| Wire colour | white/blue, white/orange, white/green, white/brown, according to IEC 60189 and IEC 60708 |
| Imprint | DATWYLER «cable type» «additional text» «batch number» «meter marks» |
| Field of application | Industrial |
| Reaction to fire | EN 13501-6 |
|---|---|
| Euroclass | Dca |
| Smoke density | IEC 61034-1/-2, EN 61034-1/-2, VDE 0482-1034-1/-2 |
| Zero halogen no corrosive gases | IEC 60754-1/-2, EN 60754-1/-2, VDE 0482-754-1/-2 |
| Flame propagation | IEC 60332-1-2, EN 60332-1-2, VDE 0482-332-1-2 |
| Cables standard | ISO/IEC 61156-6, EN 50288-4-2 |
| Cat./Class | Cat.7 / Class F |
| PoE | IEEE 802.3bt |
| UL certification | UL 444, CMG |
| Outer sheath material | FRNC/LSZH |
|---|
