110 series patch cord, 1P, 2P flex

Cable de parcheo de voz flexible, U/UTP, AWG 24

110 series flex voice patch cords

Variantes de productos y existencias

Artículo No. Stock Product no.ProdottoConnector type side AConnector type side BLongitud (m)Peso [kg]
4109788
CJ100-R1-V01M0CJ 100 1P flexRJ4511010.05 kg
4109789
CJ100-R1-V02M0CJ 100 1P flexRJ4511020.1 kg
4109790
CJ100-R1-V03M0CJ 100 1P flexRJ4511030.15 kg
4109791
CJ250-R1-V01M0CJ 250 2P flex, data transmissionRJ4511010.05 kg
4109792
CJ250-R1-V02M0CJ 250 2P flex, data transmissionRJ4511020.1 kg
4109793
CJ250-R1-V03M0CJ 250 2P flex, data transmissionRJ4511030.15 kg
4109794
CJ200-R1-V01M0CJ 200 2P flex, voice transmissionRJ4511010.05 kg
4109795
CJ200-R1-V02M0CJ 200 2P flex, voice transmissionRJ4511020.1 kg
4109796
CJ200-R1-V03M0CJ 200 2P flex, voice transmissionRJ4511030.15 kg
4109797
CJ100-11-V01M0CJ 100 1P flex11011010.05 kg
4109798
CJ100-11-V02M0CJ 100 1P flex11011020.1 kg
4109799
CJ100-11-V03M0CJ 100 1P flex11011030.15 kg
4109800
CJ230-R1-V01M0CJ 230 2P flexRJ11RJ4510.05 kg
4109801
CJ230-R1-V02M0CJ 230 2P flexRJ11RJ4520.1 kg
4109802
CJ230-R1-V03M0CJ 230 2P flexRJ11RJ4530.15 kg

Especificaciones técnicas

Flexible patch cord for the transmission of voice signals.
Meets the requirements of EN 50173.1-2007, ISO 11801-2002 and ANSI-EIA/TIA 568.C2.
Equipped with an RJ45 or 110 connector on one cable end and a 110 or RJ11 connector on the other.
Available in different standard lengths.
Impresión de aplicaciones ENTDECKT Para la transmisión de señales de voz.
Temperatura de funcionamiento -20 °C - +75 °C
Color de la funda exterior gris
