CU 6052 4P / 2x4P F8
Data cable, F/FTP, Category 6, AWG23, Euroclass B2ca
300 MHz
1 Inner conductor: AWG23 Bare copper wire
2 PE insulated conductor: 1.3 mm Ø
3 Screen (pair): Alu PETP foil
4 Overall screen: Alu PETP foil
5 Drain wire: Tinned copper wire
6 Outer sheath: FRNC/LSOH Orange RAL 2003
Product variants & stock
Download
| Article No. | Stock | Product | Reaction to fire | Dimensions n x p x [mm (AWG)] | Outer sheath dimensions [mm] | CU rate [kg/km] | Weight [kg/km] | Fire load [kWh/m] | Packing unit | GTIN / EAN |
|---|---|---|---|---|---|---|---|---|---|---|
| 18851200BK | CU 6052 4P | B2ca-s1a,d1,a1 | 4 x 2 x 0.55 (AWG23) | 7 | 20.0 | 48.4 | 0.144 | 1000 m drum | 40393910034394 |
Technical specifications
Electrically and mechanically superior quality Cat.6 data cable - exceeds the requirements of ISO/IEC 11801, IEC 61156-5, EN 50173-1 and EN 50288-5-1.
Good shielding effect due to individually screened pairs and overall foil screen.
Compatible with all current connecting hardware in accordance with EN 50173 and ISO/IEC 11801.
Good shielding effect due to individually screened pairs and overall foil screen.
Compatible with all current connecting hardware in accordance with EN 50173 and ISO/IEC 11801.
| Data cable for structured premises cabling. For the transmission of digital and analogue voice, video and data signals. Suitable for all ICT network applications up to class E applications (250 MHz) in accordance with EN 50173-1 and ISO/IEC 11801. Applicable for Power over Ethernet (PoE) / PoE+. |
| AWG | 23 |
|---|---|
| Solid / Flex | Solid wire |
| Minimum bending radius (permanently installed) | 28 mm |
| Minimum bending radius (during installation) | 56 mm |
| Tensile strength (2x4P) | 190 N |
| Tensile strength (4P) | 95 N |
| Minimum number of impacts | 10 |
| Minimal crush resistance / 10cm | 1000 N |
| Category | Cat.6 |
|---|---|
| GBit/s | Up to 1 Gbit/s |
| Loop resistance at 20 °C | 150 Ω/km |
| Operating capacity | 42 pF/m |
| Impedance at 100 MHz, ±5Ω | 100 Ω |
| NVP % | 79 |
| Delay skew | 5 ns/100 m |
| Shielding | shielded |
| Near end unbalance attenuation LCL at 1-600 MHz | 40 dB |
| Transfer impedance 1/10/30 MHz | < 50/100/200 mΩ/m |
| Coupling attenuation | 65 dB |
| Segregation class | c |
| Installation temperature | 0 °C - +50 °C |
|---|---|
| Operating temperature | -20 °C - +60 °C |
| Wire colour | white/blue, white/orange, white/green, white/brown, according to IEC 60189 and IEC 60708 |
| Imprint | DATWYLER «cable type» «additional text» «batch number» «meter marks» |
| Field of application | Indoor |
| Reaction to fire | EN 13501-6 |
|---|---|
| Euroclass | B2ca |
| Smoke density | IEC 61034-1/-2, EN 61034-1/-2, VDE 0482-1034-1/-2, AREI-RGIE Section 4.3.3 SD |
| Zero halogen no corrosive gases | IEC 60754-1/-2, EN 60754-1/-2, VDE 0482-754-1/-2, AREI-RGIE Section 4.3.3 SA |
| Flame propagation | IEC 60332-1-2, EN 60332-1-2, VDE 0482-332-1-2, AREI-RGIE Section 4.3.3 F1 |
| Flame spread | IEC 60332-3-24, EN 60332-3-24, AREI-RGIE Section 4.3.3 F2 |
| Cables standard | ISO/IEC 61156-5, EN 50288-5-1 |
| Cat./Class | Cat.6 / Class E |
| PoE | IEEE 802.3bt Type 4 (100W) |
| Outer sheath material | FRNC/LSZH |
|---|---|
| Outer sheath colour | orange |
